MV6835 Mityvac Vacuum Brake Bleed Kit

MV6835 Mityvac Vacuum Brake Bleed Kit

Price $197.99


Product Code: MTYMV6835
Qty:

Description Prop65

Model MV6835 extends the capabilities of our MV6830 vacuum brake bleeder by including our MVA6832 Clamp-on Auto-refill Kit. While the bleeder can evacuate up to 2 quarts (2 liters) per minute, the refill kit ensures the master cylinder does not run dry of new fluid, making this kit an extremely efficient method of bleeding hydraulic brake and clutch systems.
Product Features
  • Compressed air operation
  • Integrated 1.9 quart (1.8 liter) capacity fluid collection reservoir
  • Variable control thumb throttle
  • Swivel air inlet with quick disconnect
  • Automatically maintains fluid level in master cylinder
  • Two refill kit styles ensure a fit to all makes and models of vehicles
Includes:
  • Brake bleeder
  • 6' (1.8 m) long bleed hose assembly
  • 4' (1.2 m) long fluid evacuation hose
  • Molded base with screws for bench mounting
  • Hanging hook
  • 3 Universal bleed screw adapters
  • Clamp-on style auto-refill kit (MVA6832)
  • User Manual (English/French/Spanish/German)
Specifications:
Bleeder Reservoir Capacity: 1.9 quarts (1.8 liters)
Refill Reservoir Capacity: 40 oz (1.2 liters)
Working Pressure: 60 – 150 psi (4.1 – 10.3 bar)
Vacuum @ 90 psi (6.2 bar): 26 in. Hg (88 kPa)
Air Consumption @ 90 psi (6.2 bar): 4.3 cfm (2.0 l/s)
Flow Rate:
@ 60 psi (4.1 bar): 50 oz/min (1460 ml/min)
@ 90 psi (6.2 bar): 70 oz/min (2100 ml/min)
@ 150 psi (10.3 bar): 70 oz/min (2100 ml/min)
Inlet Thread Size: 1⁄4" NPT
Packaged Weight: 5.1 lbs (2.3 kg)
Size: 11.5" wide x 10.8" tall x 8.8" deep (290 mm wide x 275 mm tall x 225 mm deep)
