Product Features
- Platinum 3 CFM (85 l/m) vacuum pump
- 1/2 HP, 1725 RPM capacitor start motor with thermal overload protection
- 1/4” x 3/8”intake port
- Voltage 115 Volt 60 Hertz
- 27 ounce (798 cc) oil capacity
- Gas ballast increases and keeps oil cleaner
- 2 stage direct drive to achieve deep 15 micron vacuum
- Check valve prevents oil back flow during power failure
- Low profile rocker switch
- Lift ring to hoist
- Tethered safety cap prevents oil spills during transport
- 1/2" NPT break resistant handle encompasses exhaust
- Lighter weight finned aluminum housing reduces heat during operation
- Well-protected drain valve sealed with O-ring to prevent leaks
- All metal construction including all brass fittings
- Completely field repairable
- UL listed
- Made in the USA
|
DV-42N
|
DV-85N
|
DV-142N
|
DV-200N
|
DV-285N
|
|
CFM
|
1.5 CFM (42 l/m)
|
3 CFM (85 l/m)
|
5 CFM (142 l/m)
|
7 CFM (200 l/m)
|
10 CFM (285 l/m)
|
|
Motor
|
1/2 HP, 1725 RPM
|
1/2 HP, 1725 RPM
|
1/2 HP, 1725 RPM
|
1/2 HP, 1725 RPM
|
1/2 HP, 1725 RPM
|
|
Voltage
|
115v, 60Hz
|
115v, 60Hz
|
115v, 60Hz
|
115v, 60Hz
|
115v, 60Hz
|
|
Plug
|
Std. U.S. 110v
|
Std. U.S. 110v
|
Std. U.S. 110v
|
Std. U.S. 110v
|
Std. U.S. 110v
|
|
Intake Port
|
1/4" Flare
|
1/4" x 3/8" Flare
|
3/8" x 1/4" x 3/8" Flare
|
3/8' x 1/4" x 3/8" Flare
|
3/8" x 1/4" x 3/8" Flare
|
|
Oil Capacity
|
27 oz. (798 cc)
|
27 oz. (798 cc)
|
23 oz. (680 cc)
|
23 oz. (680 cc)
|
24 oz. (709 cc)
|
|
Dimensions
|
17-5/8 (h) x 91/8" (w) x 14" (l)
|
17-5/8 (h) x 91/8" (w) x 14" (l)
|
17-5/8 (h) x 91/8" (w) x 14" (l)
|
17-5/8 (h) x 91/8" (w) x 14" (l)
|
17-5/8 (h) x 91/8" (w) x 14" (l)
|
|
Weight
|
29 lbs. (13.2 Kg)
|
30 lbs. (13.6 Kg)
|
32 lbs. (14.5 Kg)
|
32 lbs. (14.5 Kg)
|
34 lbs. (15.4 Kg)
|
|
|
|
|
|
|
|
