You are here: Home > Chicago Pneumatic Air Sanders and Polishers > Chicago Pneumatic CP763 Air Sander Repair Parts

Chicago Pneumatic CP763 Impact Wrench Repair Parts


Index
No.
Part No. Description No.
Req'd
1 CA147388 Housing - Motor 1
4 CA147389 Lever - Throttle 1
5 CA147390 O-Ring (4.1 x 1.6) 1
6 CA147391 Stem - Throttle Valve 1
7 CA147392 Valve - Throttle 1
8 CA147393 Seat - Throttle Valve 1
9 CA147394 Spring 1
10 CA147395 O-Ring (14.1 x 1.6) 3
11 CA145755 Handle (Long) (CP763) 1
- CA148114 Handle - Palm Grip (CP763P 1
12 CA147432 O-Ring(18.1 x 1.6) 1
13 CA147397 Screw (16mm) 1
15 CA147398 Bushing - Air Inlet (1/4" NPT) 1
16 CA147399 Coupling - Vacuum Hose 1
17 C143187 Ring - Retaining 1
18 S025055 Bearing - Ball (6200 2Z) 1
19 CA147400 Spacer - Bearing 1
23 CA147401 Spacer - Bearing 1
24 CA147402 Plate - Upper End 1
25 CA147403 O-Ring (52mm x 5mm) 1
26 CA147404 Liner 1
27 C136794 Pin -Roll (3mm x 30mm) 2
29 CA147406 Shim - Spacer 1
30 C143183 Set - Rotor Blade (3) 1
31 CA147430 Ring 1
32 C143184 Rotor 1
34 CA147431 Shroud - Vacuum 1
35 CA147408 Plate -Lower End 1
36 C127936 Screw - Socket Head Cap 4
37 C143180 Key - Wodruff 1
38 CA147433 Diffuser - Exhaust 1
39 CA147434 Silencer 1
40 CA147409 Bearing - Ball (6002 2Z) 1
41 CA147410 O-Ring (6.1 x 1.6) 1
42 CA147425 Hub Orbital (CP763) 1
43 CA147411 Hub Orbital (CP763P) 1
44 CA147412 Bearing - Ball (6201 RSR) 1
45 CA147413 Washer -Waved (EPL24) 1
46 CA147414 Circlip - Internal (7000-032PF) 1
47 KF140658 Pad - Sanding Vacuum (6" dia.) 1
48 CA164433 Spanner Wrench (Not Shown) 1
Sort By:
MIL1001-4 Milton Industries Tool Oil 4oz. Flip Top 1001-4 Milton Industries Tool Oil 4oz. Flip Top

Extends life and performance of air tools, lubricators, valves and cylinders. Prevents seizure of air tools and pneumatic equipment. Recommended for tools requiring a 10 weight non-detergent lubricant. Working temperature: 5° F to 350° F.

Price $5.15
8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube 8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube

8940158455 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease 100Gm Tube

Price $29.28
8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge 8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge

8940158456 Chicago Pneumatic Pneu-Lube Synthetic Clutch Grease Cartridge

Price $36.54
C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings

C098689 Chicago Pneumatic Push-Type Hand Grease Gun For Flush Fittings

Price $15.61
C127936 Chicago Pneumatic Screw-Soc Hd Cap C127936 Chicago Pneumatic Screw-Soc Hd Cap

C127936 Chicago Pneumatic Screw-Soc Hd Cap

Discontinued
C136794 Chicago Pneumatic Pin-Roll 3x30 C136794 Chicago Pneumatic Pin-Roll 3x30

C136794 Chicago Pneumatic Pin-Roll 3x30

Discontinued
C143180 Chicago Pneumatic Key-Woodruff C143180 Chicago Pneumatic Key-Woodruff

C143180 Chicago Pneumatic Key-Woodruff

Discontinued
C143183 Chicago Pneumatic Blade Set-Rotor (3) C143183 Chicago Pneumatic Blade Set-Rotor (3)

C143183 Chicago Pneumatic Blade Set-Rotor (3)

Discontinued
C143184 Chicago Pneumatic Rotor C143184 Chicago Pneumatic Rotor

C143184 Chicago Pneumatic Rotor

Discontinued
C143187 Chicago Pneumatic Ring-Retaining C143187 Chicago Pneumatic Ring-Retaining

C143187 Chicago Pneumatic Ring-Retaining

Discontinued
CA147388 Chicago Pneumatic Housing-Motor CA147388 Chicago Pneumatic Housing-Motor

CA147388 Chicago Pneumatic Housing-Motor

Discontinued
CA147390 Chicago Pneumatic O-Ring 4.1x1.6 CA147390 Chicago Pneumatic O-Ring 4.1x1.6

CA147390 Chicago Pneumatic O-Ring 4.1x1.6

Discontinued
CA147391 Chicago Pneumatic Stem-Throttle Valve CA147391 Chicago Pneumatic Stem-Throttle Valve

CA147391 Chicago Pneumatic Stem-Throttle Valve

Discontinued
CA147392 Chicago Pneumatic Valve-Throttle CA147392 Chicago Pneumatic Valve-Throttle

CA147392 Chicago Pneumatic Valve-Throttle

Discontinued
CA147393 Chicago Pneumatic Seat-Throttle Valve CA147393 Chicago Pneumatic Seat-Throttle Valve

CA147393 Chicago Pneumatic Seat-Throttle Valve

Discontinued
CA147394 Chicago Pneumatic Spring CA147394 Chicago Pneumatic Spring

CA147394 Chicago Pneumatic Spring

Discontinued
CA147395 Chicago Pneumatic O-Ring 14.1x1.6 CA147395 Chicago Pneumatic O-Ring 14.1x1.6

CA147395 Chicago Pneumatic O-Ring 14.1x1.6

Discontinued
CA147398 Chicago Pneumatic Bushing-Air Inlet CA147398 Chicago Pneumatic Bushing-Air Inlet

CA147398 Chicago Pneumatic Bushing-Air Inlet

Discontinued
CA147399 Chicago Pneumatic Coupling-Vacuum Hose CA147399 Chicago Pneumatic Coupling-Vacuum Hose

CA147399 Chicago Pneumatic Coupling-Vacuum Hose

Discontinued
CA147401 Chicago Pneumatic Spacer-Bearing CA147401 Chicago Pneumatic Spacer-Bearing

CA147401 Chicago Pneumatic Spacer-Bearing

Price $5.76
CA147402 Chicago Pneumatic Plate-Upper End CA147402 Chicago Pneumatic Plate-Upper End

CA147402 Chicago Pneumatic Plate-Upper End

Discontinued
CA147403 Chicago Pneumatic O-Ring 52x2 CA147403 Chicago Pneumatic O-Ring 52x2

CA147403 Chicago Pneumatic O-Ring 52x2

Discontinued
CA147404 Chicago Pneumatic Liner CA147404 Chicago Pneumatic Liner

CA147404 Chicago Pneumatic Liner

Discontinued
CA147406 Chicago Pneumatic Shim-Spacer CA147406 Chicago Pneumatic Shim-Spacer

CA147406 Chicago Pneumatic Shim-Spacer

Discontinued
CA147408 Chicago Pneumatic Plate-Lower End CA147408 Chicago Pneumatic Plate-Lower End

CA147408 Chicago Pneumatic Plate-Lower End

Discontinued
CA147409 Chicago Pneumatic Bearing-Ball 6002 2z CA147409 Chicago Pneumatic Bearing-Ball 6002 2z

CA147409 Chicago Pneumatic Bearing-Ball 6002 2z

Discontinued
CA147410 Chicago Pneumatic O-Ring 6.1x1.6 CA147410 Chicago Pneumatic O-Ring 6.1x1.6

CA147410 Chicago Pneumatic O-Ring 6.1x1.6

Discontinued
CA147412 Chicago Pneumatic Bearing-Ball 6201rsr CA147412 Chicago Pneumatic Bearing-Ball 6201rsr

CA147412 Chicago Pneumatic Bearing-Ball 6201rsr

Discontinued
CA147425 Chicago Pneumatic Hub-Orbital Cp761 CA147425 Chicago Pneumatic Hub-Orbital Cp761

CA147425 Chicago Pneumatic Hub-Orbital Cp761

Discontinued
CA147430 Chicago Pneumatic Ring CA147430 Chicago Pneumatic Ring

CA147430 Chicago Pneumatic Ring

Discontinued
CA147431 Chicago Pneumatic Shroud CA147431 Chicago Pneumatic Shroud

CA147431 Chicago Pneumatic Shroud

Discontinued
CA147432 Chicago Pneumatic O-Ring 18.1x1.6 CA147432 Chicago Pneumatic O-Ring 18.1x1.6

CA147432 Chicago Pneumatic O-Ring 18.1x1.6

Discontinued
CA147433 Chicago Pneumatic Diffuser-Exhaust CA147433 Chicago Pneumatic Diffuser-Exhaust

CA147433 Chicago Pneumatic Diffuser-Exhaust

Discontinued
CA147434 Chicago Pneumatic Silencer CA147434 Chicago Pneumatic Silencer

CA147434 Chicago Pneumatic Silencer

Discontinued
CA148114 Chicago Pneumatic Handle-Palm Grip CA148114 Chicago Pneumatic Handle-Palm Grip

CA148114 Chicago Pneumatic Handle-Palm Grip

Discontinued
CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz. CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz.

CA149661 Chicago Pneumatic Oil Protecto Lube 4 Oz.

Price $4.86
CP3514 Chicago Pneumatic 5" R.O. Sander 3/16" Orbit CV, H&L CP3514 Chicago Pneumatic 5" R.O. Sander 3/16" Orbit CV, H&L

CP3514 5" R.O. Sander 3/16" Orbit CV, H&L - This 5" random orbital palm sander has a hook and loop pad, 0.3 horse power motor, ergonomic soft grip, enhanced control tear drop design, low operating noise, it is a central vacuum model and has a shut-off and speed control switch. This is a great sander for surface preparation applications.

Price $257.38
S025055 Chicago Pneumatic Bearing-Ball S025055 Chicago Pneumatic Bearing-Ball

S025055 Chicago Pneumatic Bearing-Ball

Price $24.36
