Index
No. |
Part No. |
Description |
No.
Req'd |
1 |
CA157227 |
Assembly
- Motor Housing (Model A) |
1 |
- |
CA157693 |
Assembly
- Motor Housing (Model K) |
1 |
2 |
CA157228 |
Grip
- Cushion |
1 |
3 |
CA157229 |
O-Ring
(Model A) |
1 |
- |
CA157694 |
E-Ring
(Model K) |
1 |
4 |
CA157230 |
Plug |
1 |
5 |
CA157231 |
O-Ring
(Model A) |
1 |
- |
CA157695 |
O-Ring
(Model K) |
2 |
6 |
CA157232 |
Valve
- Reverse (Model A) |
1 |
- |
CA157696 |
Valve
- Reverse (Model K) |
1 |
7 |
CA157233 |
Stem
- Trigger (Model A) |
1 |
- |
CA157697 |
O-Ring
(Model K) |
1 |
8 |
CA157234 |
O-Ring |
2 |
9 |
CA157235 |
Bushing
- Trigger (Model A) |
1 |
- |
CA157698 |
Bushing
- Trigger (Model K) |
1 |
10 |
CA157236 |
Retainer |
1 |
11 |
CA157237 |
Trigger
(Model A) |
1 |
- |
CA157699 |
Pin
- Trigger (Model K) |
1 |
12 |
CA157238 |
Screw |
2 |
13 |
CA157239 |
Retainer |
1 |
14 |
CA157240 |
Adapter
- Inlet |
1 |
15 |
CA157241 |
Valve
- Tilt |
1 |
16 |
CA157242 |
Spring
- Throttle |
1 |
17 |
CA157243 |
O-Ring |
1 |
18 |
CA157244 |
Regulator
- Assembly (Incl Index Nos: 55 & 56) |
1 |
19 |
CA157245 |
Pin |
1 |
20 |
CA157246 |
Seal
- Oil |
1 |
21 |
CA157247 |
Bushing
- Anvil |
1 |
22 |
CA157283 |
Anvil
Assembly (1/4 in sq)(Incl Index Nos: 40
& 41)(CP719 only) |
1 |
22A |
CA157287 |
Anvil
- 1/4 Hex (CP719QC) |
1 |
23 |
CA157249 |
Cage |
1 |
24 |
CA157250 |
Pin
- Cage |
2 |
25 |
CA157251 |
Hammer |
1 |
26 |
CA146691 |
O-Ring |
1 |
27 |
CA157253 |
Bearing |
1 |
28 |
CA157254 |
Seal
- Oil |
1 |
29 |
CA157255 |
O-Ring |
1 |
30 |
CA157256 |
Plate
- Front End |
1 |
31 |
CA157257 |
Liner |
1 |
32 |
CA157258 |
Rotor |
1 |
33 |
CA157284 |
Blade
Set - Rotor (6) |
1 |
34 |
CA157260 |
Pin |
1 |
35 |
CA157261 |
Plate
- Rear End |
1 |
36 |
CA157262 |
Bearing |
1 |
37 |
CA157263 |
Gasket
(Model A) |
1 |
- |
CA157700 |
Gasket
(Model K) |
1 |
38 |
CA157264 |
Cover
- Motor Housing (Model A) |
1 |
- |
CA157701 |
Cover
- Motor Housing (Model K) |
1 |
39 |
CA157265 |
Screw
with Lockwasher |
1 |
40 |
CA157266 |
Ring
- Socket Retaining (CP719 only) |
4 |
41 |
CA157267 |
O-Ring
(Anvil) |
1 |
42 |
CA146654 |
O-Ring
(Not used on Model K) |
1 |
43 |
CA157269 |
Strainer
- Air |
1 |
44 |
CA157270 |
Muffler |
1 |
52 |
CA157271 |
Bushing
- Regulator |
1 |
53 |
CA157272 |
O-Ring |
1 |
54 |
CA157273 |
O-Ring
(Not Shown) |
1 |
- |
CA157274 |
Bushing
- Tilt Valve |
1 |
55 |
CA157275 |
Ball
- Steel |
1 |
56 |
CA157276 |
Spring
- Detent |
1 |
57 |
CA157277 |
Bushing
- Reverse Valve (Model A) |
1 |
- |
CA157702 |
Bushing
- Reverse Valve (Model K) |
1 |
194 |
C077720 |
Sleeve
(CP719QC) |
1 |
195 |
S008613 |
Ball
(CP719QC) |
1 |
196 |
C077721 |
Spring
(CP719QC) |
1 |
197 |
C077722 |
Washer
(CP719QC) |
1 |
198 |
C078709 |
Ring
- Retaining (CP719QC) |
1 |
Tune-Up
Kit |
CA157285 |
Incl Index Nos: 3, 5, 7 (Model K), 8, 17,
20, 26, 28, 29, 33, 37, 40, 41, 42, 53 & 54 |
Repair
Kit |
CA157286 |
(CP719 1/4" Sq. Dr.)(Incl All Parts in
Tune-Up
Kit Plus Index Nos: 22 & 24)(excludes 40 & 41) |
