Chicago Pneumatic CP5080-3260D12 Belt Sander Repair Parts



Index
No.
Part No. Description No.
Req'd
A
6154600400
Regulator Assembly
-
3
-
Regulator
1
4
-
O-Ring (8.1 x 1.6) 1
5
-
O-Ring (8 x 1) 1
6
-
Spring ring WR9
1
7
-
Valve stem
1
8
-
O-Ring (2 x 1) 1
B
2050546343
Valve Kit
-
9
-
Tip valve
1
10
-
Spring
1
C
2050546353
Front Plate Assembly
-
26
-
Front plate
1
27
-
Washer
1
28
6157581380
Bearing 608Z (8 x 22 x 7)
1
29
-
Pin spring (2.5 x 4)
1
D
2050546363
Rear Plate Assembly
-
29
-
Pin spring (2.5 x 4)
1
30
-
Rear plate
1
32
6157580630
Bearing 625ZZ (5 x 16 x 5)
1
E
2050546373
Motor Assembly
-
C
2050546353
Front plate assembly
1
D
2050546363
Rear plate assembly
1
25
6154001500
Cylinder
1
31
6154261210
Motor M8
1
33
2050547783
Blades (set of 4)
1
F
2050546413
Small Parts Kit
-
6
-
Spring ring WR9
1
8
-
O-Ring (2 x 1) 1
12
-
O-Ring (27 x 2) 1
14
-
Needle (2.5 x 11.8)
1
17
-
O-Ring (17 x 2) 1
21
-
O-Ring (10.5 x 1.5) 1
37
-
External ring
1
38
-
Spacer
1
39
-
O-Ring (15.6 x 1.78)
1
G
2050546403
Tune-up Kit
-
2
-
Seal
1
16
-
Felt
1
33
2050547783
Blades (set of 4)
1
22
-
Paper gasket
1
-
1
2050547773
Handle assembly (incl 15)
1
11
6155740660
Air control ring
1
13
2050541493
Sagety lever
1
15
-
Rear cap
1
18
2050542533
Insert assembly
1
19
6153212410
Insert
1
20
6156561900
Rubber gasket
1
23
6157301890
Nut
1
24
6155653210
Motor housing
1
34
6156452300
Spacer
1
35
6159901830
Wheel
1
36
6156731400
Cover
1
-
2050554263
Hex wrench (3 mm)
1
-
6158727980
Warning label
1
-
A
2050546303
Small Parts Kit 12" Guard
-
3
-
Spring
2
7
-
Pin
1
8
-
Spring
1
9
-
Lock
1
10
-
Knob
1
-
-
Lock screw (not shown)
1
-
1
-
Body guard
1
2
-
Spindle case
1
4
-
Spindle case
1
5
-
Ring
2
6
-
Washer
2
11
2050545863
Guard assembly
1
