Index
No. |
Part No. |
Description |
No.
Req'd |
-
|
6155041810
|
Complete guard 6" CE
CP3349-SALAVETE
|
1
|
-
|
6155041820 |
Complete guard 7" CE
CP3349-SALAVADE |
1
|
-
|
6155041830 |
Complete guard 9" CE
CP3349-SALAVELE |
1
|
-
|
6155041780 |
Complete guard 6" US
CP3349-SALAVET |
1
|
-
|
6155042250 |
Complete guard 9" US
CP3349-SALAVEL |
1
|
-
|
6155031160
|
Rear flange for
CP3349-SALAVETE (6" CE) |
1
|
-
|
6155031070 |
Rear flange
CP3349-SALAVEL (9" US) |
1
|
-
|
6155031030 |
Rear flange
CP3349-SALAVADE (7" CE) / CP3349-SALAVELE (9" CE) |
1
|
-
|
6155421040
|
Nut CP3349-SALAVADE (7"
CE) / CP3349-SALAVELE (9" CE) /
CP3349-SALAVEL (9" US) |
1
|
-
|
6156140340
|
Safety screw
CP3349-SALAVETE (6" CE) / CP3349-SALAVADE (7" CE)
CP3349-SALAVELE (9" CE) / CP3349-SALAVEL (9" US) |
1
|
-
|
6156101050
|
Screw CP3349-SALAVETE
(6" CE) / CP3349-SALAVET (6" US) |
5
|
|
6156101050
|
Screw CP3349-SALAVADE (7" CE) /
CP3349-SALAVELE (9" CE) |
2
|
-
|
6156101070
|
Screw CP3349-SALAVEL (9"
US) |
5
|
|
6156101070 |
Screw CP3349-SALAVADE (7" CE) /
CP3349-SALAVELE (9" CE) |
3
|
-
|
6158010770
|
Spanner flat
CP3349-SALAVETE (6" CE) / CP3349-SALAVADE (7" CE)
CP3349-SALAVELE (9" CE) / CP3349-SALAVEL (9" US)
|
1
|
-
|
6158020100
|
Pin spanner
CP3349-SALAVADE (7" CE) CP3349-SALAVELE (9" CE) |
1
|
-
|
6158020560
|
Hex. wrench 6 mm
CP3349-SALAVETE (6" CE) / CP3349-SALAVADE (7" CE)
CP3349-SALAVELE (9" CE) / CP3349-SALAVEL (9" US) |
1
|
-
|
6158020610
|
Hex. wrench 8 mm
CP3349-SALAVET (6" US) |
1
|
-
|
6155952020
|
Lever CP3349-SALAVET (6"
US) |
1
|
-
|
C087920
|
Wheel adapter for
CP3349-SALAVEL (9" US)
|
1
|
-
|
6156452180
|
Spring washer
|
1
|
20
|
6153965650
|
Handle kit
|
-
|
21
|
6153210830
|
Lever
|
|
22
|
6153212140 |
Latch lever
|
|
23
|
6156811210 |
Latch lever spring
|
|
24
|
6156380140
|
Grooved pin
|
|
25
|
6156380150
|
Grooved pin
|
|
26
|
6157460740
|
Bushing inlet
|
|
27
|
6156581150
|
O-Ring
|
|
28
|
744.08
|
Screen
|
|
29
|
6156810200
|
Ball spring
|
|
30
|
6157700190
|
Ball
|
|
31
|
6153210800
|
Ball seat
|
|
32
|
6157901350
|
Needle
|
|
33
|
6156811230
|
Lever spring
|
|
34
|
6156583160
|
O-Ring
|
|
35
|
6156100930
|
Screw
|
|
B
|
6153932660
|
Housing Complete (CP3349-SALAVADE) (7" CE)
|
-
|
B
|
6153932680
|
Housing Complete
(CP3349-SALAVELE) (9" CE) |
-
|
B
|
6153932720
|
Housing Complete (CP3349-SALAVETE) (6" CE) /
(CP3349-SALAVET) (6" US)
|
-
|
B
|
6153932770
|
Housing
Complete (CP3349-SALAVEL) (9" US) |
|
40
|
6155652820
|
Housing (CP3349-SALAVADE) (7" CE) |
-
|
40
|
6155652840
|
Housing (CP3349-SALAVELE) (9" CE) |
-
|
40
|
6155652860
|
Housing (CP3349-SALAVETE) (6" CE) /
(CP3349-SALAVET) (6" US) |
-
|
40
|
61556529100
|
Housing
(CP3349-SALAVEL) (9" US) |
-
|
42
|
6156540400
|
Felt
|
-
|
43
|
6153212320
|
Oil tank down
|
-
|
44
|
658.120
|
O-Ring
|
-
|
45
|
6156500250
|
Washer
|
-
|
46
|
6156140270
|
Oil plug
|
-
|
47
|
6158727470
|
Tool label
|
-
|
48
|
6156340220
|
Grooved nail
|
-
|
49
|
6156340560
|
Exhaust grid
|
-
|
50
|
6156180180
|
Screw
|
-
|
51
|
6156582620
|
O-Ring |
-
|
52
|
6153212310
|
Oil tank up complete
|
-
|
53
|
6155760720
|
Side handle complete
|
-
|
60
|
400.120
|
Cylinder
|
-
|
61
|
420.119
|
Front plate
|
-
|
62
|
422.129
|
End plate
|
-
|
62
|
6154221490
|
End plate CP3349-SALAVEL (9" US)
/ CP3349-SALAVET (6"US)
|
-
|
63
|
426.62
|
Rotor
|
-
|
63
|
6154261030
|
Rotor CP3349-SALAVEL (9" US) /
CP3349-SALAVET (6"US) |
-
|
64
|
434.48
|
Rotor vane
|
-
|
65
|
457.18
|
Governor CP3349-SALAVETE (9" CE) / CP3349-SALAVADE (7" CE) /
CP3349-SALAVEL (6" CE)
|
-
|
66
|
661.75
|
Spacer |
-
|
67
|
607.49
|
Nut
|
-
|
68
|
557.93
|
Flange CP3349-SALAVETE (9" CE) / CP3349-SALAVADE (7" CE) /
CP3349-SALAVEL (6" CE) |
-
|
69
|
|
Plug
|
-
|
70
|
6156811050 |
Governor spring 7700 rpm CP3349-SALAVADE (7" CE) |
-
|
70
|
681.33 |
Governor spring 6500 rpm CP3349-SALAVELE (9" CE) |
-
|
70
|
6156811040 |
Governor spring 6000 rpm for CP3349-SALAVEL (9" US) /
CP3349-SALAVET (6" US) / CP3349-SALAVETE (6" CE) |
-
|
71
|
6153211830
|
Governor housing
|
-
|
72
|
658.118
|
O-Ring
|
-
|
73
|
658.120
|
O-Ring |
-
|
74
|
754.17
|
Bearing
|
-
|
75
|
758.17
|
Bearing
|
-
|
76
|
6155031500
|
Rear flange CP3349-SALAVET (6" US) |
-
|
76
|
6155031070
|
Rear flange CP3349-SALAVEL (9"
US) |
-
|
77
|
6156581240
|
O-Ring for CP3349-SALAVEL (9" US) /
CP3349-SALAVET (6" US) |
-
|
78
|
6154570320
|
Governor for CP3349-SALAVEL (9" US) /
CP3349-SALAVET (6" US) |
-
|
78B
|
6153201280
|
Ring overspeed for CP3349-SALAVEL (9" US) /
CP3349-SALAVET (6" US) |
-
|
88
|
6155031460
|
Rear flange balancer
|
-
|
93
|
6158010770
|
Spanner flat
|
-
|
94
|
6158020560
|
Hexagon wrench
|
-
|
95
|
6156140340
|
Screw
|
-
|
100
|
6155421040
|
Nut
|
-
|
101
|
6158020100
|
Pin spanner (35 mm)
|
-
|
C
|
399.463
|
Silencer Assembly
|
-
|
81
|
399.736
|
Silencer
|
-
|
82
|
637.50
|
Pin
|
-
|
83
|
658.164
|
O-Ring |
-
|
84
|
730.172
|
Bushing
|
-
|
85
|
658.246
|
O-Ring
|
-
|
86
|
6155740570
|
Gasket
|
-
|
-
|
93
|
6158010770
|
Spanner flat
|
-
|
94
|
6158020560
|
Hexagon wrench (6 mm)
|
-
|
95
|
6156140340
|
Screw
|
-
|
96
|
6155031030
|
Rear flange
|
-
|
100
|
6155421040
|
Nut
|
-
|
101
|
6158020100
|
Pin spanner (35 mm)
|
-
|
102
|
6156080490
|
Nut
|
-
|
103
|
6158010770
|
Spanner flat
|
-
|
