Associated Pointer Knob with spring clip (Press-On). Fits 1/2 round shaft switches and timers only. For 3/4 round shaft applications see 610930.

Front Leg With Screws

605672 Associated Wheel Kit With Nuts 6" Plastic 3/8" hub diameter

DC CABLE SET

610043 Associated 3/8 Axle Cap (Each)

610052 Associated Axle With Nuts. Axle 3/8" O.D. x 15-3/4" Long

Associated 610180 KNOB

610258 Associated DC Cable Set 7 ft 4 AWG , Replaces 605677

610277 Associated Switch SPDT 8400

Associated 610278 Ammeter Horizontal 0-50 Amp Range w/ Boost. Brass Threaded Terminals For Ring Terminal Connections and Snap-In Mounting For Easy Installation.

CIRCUIT BREAKER DC

This kit provides everything needed to replace older obsolete electrical driven timers with a new spring wound mechanical timer. The kit includes Knob, wiring and electrical connections, wire ties, spade terminals for universal applications and instructions.

*If your unit has an Older 90 Minute mechanical timer, use the 611254 retrofit kit to simplify the install. If your unit has an electric 120 minute timer, use the 611245 which is a direct replacement for those units.

Associated 610392 Rectifier Installation Kit. The Highest rated Rectifier in the market, completely assembled

610417 Associated Rectifier Kit 8400 & 6011

Mechanically controls charging in timed Mode with manual hold mode. Two Independent Single Pole Single Throw (SPST) Switches rated 15 amperes. 1/4" spade terminals. Timer has Hold Position.
*See 611254 retrofit Timer kit.

610931 Associated Knob with set screw for controls with 1/4" Stem.

611245 Associated 120 Minute Electronic Timer with Knob, for use in units with a 120 minute timer already installed. The timer controls battery charging in timed Mode and has a manual hold mode for longer charging cycles. Switch circuits are rated 15 amperes. Termination is designed to accept standard 1/4" spade terminals.

*If your unit has an Older 90 Minute mechanical timer, use the 611254 retrofit kit to simplify the install. If your unit has an electric 120 minute timer, use the 611245 which is a direct replacement for those units.

611254 Associated 120 Minute Electronic Timer with Knob, retrofit for units with a mechanical timer. The timer controls battery charging in timed Mode and has a manual hold mode for longer charging cycles. Switch circuits are rated 15 amperes. Termination is designed to accept standard 1/4" spade terminals.

*If your unit has an Older 90 Minute mechanical timer, use the 611254 retrofit kit to simplify the install. If your unit has an electric 120 minute timer, use the 611245 which is a direct replacement for those units.
