16600 Robinair Corona Discharge Refrigerant Leak Detector

16600 Robinair Corona Discharge Refrigerant Leak Detector



Product Code: RO16600
Discontinued See LD5

Description Prop65

The Robinair 16600 is an electronic leak detector used to detect refrigerant leaks in air conditioning and refrigeration systems. It features a sensitivity selection switch which allows it to be used with CFCs and HCFCs at one setting and HFCs at the other. The unit is able to detect leaks smaller than 1/2 ounce per year.
Other features include audible and visual leak indicators, a volume control, a threshold balancing control and a 16" gooseneck probe, which holds its position for one-handed operations. When the unit is not being used, the probe wraps into a retaining clip on the back of the case.
Product Features
  • For all CFC, HCFC and HFC Refrigerants
  • One-Hand Operation
    • The 16" gooseneck probe holds its position so you can operate the detector with one hand
  • Audible and Visual Leak Indicators
    • Threshold Balancing Control Gives you infinite control for eliminating background contamination so you can zero in on the leak site
    • Volume Control
  • Dependable Leak Detecting
    • The 16600 uses proven corona discharge technology to sense leaks. It works by creating a high voltage corona in the sensing tip. When this field is interrupted by refrigerant, the alarm is triggered. All corona discharge leak detectors are not the same, however, the quality of key components is critical in providing an effective instrument
  • Sensing Tip; The materials, shape and finish of the sensor and surrounding shell are critical to the effectiveness and life ot the tip. The 16600 is built with a mirror finish and specially engineered tip for superior sensitivity and durability. The tip can be cleaned for even longer life
Specifications
Power Source: Four AA alkaline batteries (included)
Battery Life: Approximately 25 hours
Dimensions: 8-1/2" L x 3-1/4" W x 2" D (21.59 cm x 8.26 cm x 5 cm)
Probe Length: 16 in. (40.6 cm)
Weight: 1.14 lbs (.52 kg) with batteries
(2N08) Refrigerant Leak Detection Equipment Design Certified by Underwriters Laboratories, Inc.® to meet SAE J-1627 (1993) for R-12 and R-134a refrigerants.
