You are here: Home > Battery Charger Parts > Century Battery Charger Repair Parts > 141-163 Sears 60/250 amp battery charger
141-163 Sears 60/250 amp
Sort By:
Page of 1
083-265-000 Stainless Steel Sheet Metal Screw (20 Pack) 083-265-000 Stainless Steel Sheet Metal Screw (20 Pack)

#10 1/2" Pan Head A2 Phillips Head Stainless Steel Sheet Metal Screw 20 Pack. Replace those unsightly rusting, loose or missing cabinet screws with our Stainless screws for a neat finish. Oversized to accommodate loose cabinet or stripped holes.

Price $2.85
238-006-666 Clamp Kit 8 Foot 6 Gauge Parrot Jaw 238-006-666 Clamp Kit 8 Foot 6 Gauge Parrot Jaw

8' 6AWG Welding Wire Lead Set with heavy duty polished clamps featuring coated clamp handles. a 50 lb. Jaw Strength provides positive connections and color coded wires make for easy identification. These even have molded strain relief built on the cables. Ring terminal connections make installation a snap.

Price $67.05
238-260-666 Century Positive Cable & Clamp Assembly 6ga 106" 238-260-666 Century Positive Cable & Clamp Assembly 6ga 106"

238-260-666 Century Positive Cable & Clamp Assembly 6ga 106" for Century / Solar battery chargers. Universal Style for other chargers. Booster Clamp features 6 Gauge solid copper wire, dual power jaws for better conductivity with a braided internal power crossover strap (distributes full power to both jaws), heavy duty construction for durability and long life.

Price $29.50
238-261-666 Century Negative Cable & Clamp Assembly 6ga 106" 238-261-666 Century Negative Cable & Clamp Assembly 6ga 106"

238-261-666 Century Negative Cable & Clamp Assembly 6ga 106" for Century / Solar battery chargers. Universal Style for other chargers. Booster Clamp features 6 Gauge solid copper wire, dual power jaws for better conductivity with a braided internal power crossover strap (distributes full power to both jaws), heavy duty construction for durability and long life.

Price $29.50
244-047-666 50 Amp Diode Replacement Kit (4) 244-047-666 50 Amp Diode Replacement Kit (4)

244-047-666 50 Amp Diode Replacement Kit (4). Observe correct polarity when installing. Color ring denotes cathode end. Replace all diodes in the same orientation as original diodes.

Discontinued
246-041-666 Universal Selector Knob 246-041-666 Universal Selector Knob

246-041-666 Universal Selector Knob with set screw for controls with 1/4" Stem. Replaces all knobs with 1/4" diameter shaft. Fits 1/2 shaft and 3/4 style shaft stems.

Price $7.65
246-057-000 Rotary Selector Switch 246-057-000 Rotary Selector Switch

246-057-000 Rotary Selector Switch

Discontinued See 246-058-666
246-057-200 Rotary Selector Switch 246-057-200 Rotary Selector Switch

246-057-200 Rotary Selector Switch

Discontinued See 246-058-666
246-058-666 6 Position Rotary Selector Switch 246-058-666 6 Position Rotary Selector Switch

6 Position Rotary Selector Switch with off. Replaces older 246-057-000, 246-057-100, 246-057-200 and 246-057-666 switches. Installation requires drilling mounting holes. Several different styles of switches were used under the old part number 246-057-XXX. Although slightly different, they are completely interchangeable. The new style switch 246-058-666 has different mounting and the wiring is slightly different. Included is a mounting template for drilling holes in your cabinet and a wiring connection chart for ease of installation. Screws and mounting template included. For knob see 246-041-666.
TO EASE INSTALLATION DO NOT REMOVE THE WIRES FROM YOUR OLD SWITCH UNTIL THE NEW PART ARRIVES

Price $49.95
246-078-666 Test Switch SPDT Momentary 246-078-666 Test Switch SPDT Momentary

Mini snap-in paddle handle rocker switch with are single pole double throw momentary contact arrangement ON-OFF-(ON) momentary and a 10 amp rating.

Price $8.45
246-273-666 Universal Mechanical Timer 2 Hour With Knob 246-273-666 Universal Mechanical Timer 2 Hour With Knob

120 Minute mechanical timer with knob. 120 minute total time two 1/4 spade terminal connections, no finish bell. Replaces older timer 246-337-000, 246-167-000, 246-167-666. Mounting on your timer may be different than the replacement, inspect your unit before purchase, some older units may have had electric timers which may require rewiring. (Includes Screws)

Discontinued see 0099000094
246-385-000 Circuit Breaker SLA-135 246-385-000 Circuit Breaker SLA-135

246-385-000 Circuit Breaker SLA-135, Open construction, automatic reset, no terminal Hardware

Discontinued See 246-211-666
247-074-666 Ammeter Horizontal 0-60 Amp Range W/Start 247-074-666 Ammeter Horizontal 0-60 Amp Range W/Start

Ammeter Horizontal 0-60 AMP features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and bolt through induction pick-up for greater accuracy.

Discontinued
247-132-000 Ammeter Horizontal 0-60 Amp Range 247-132-000 Ammeter Horizontal 0-60 Amp Range

Ammeter Horizontal 0-60 AMP features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and wire through induction pick-up for greater accuracy. Replaces old style bolt through meters.

Discontinued See 247-147-000
247-147-000 Ammeter Horizontal 0-60 Amp 247-147-000 Ammeter Horizontal 0-60 Amp

247-147-000 Ammeter Horizontal 0-60 Amp features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and wire through induction pick-up for greater accuracy. Replaces old style bolt through meters.

Discontinued
247-158-666 Ammeter Horizontal 0-60 Amp Range 247-158-666 Ammeter Horizontal 0-60 Amp Range

Ammeter Horizontal 0-60 AMP features easy snap-in installation. Green Red Charge Rate face. 0-60 Amp range and wire through induction pick-up for greater accuracy. Replaces old style bolt through meters.

Discontinued See 247-132-000
249-066-666 Solar Booster Clamps Positive & Negative 249-066-666 Solar Booster Clamps Positive & Negative

Clamps Positive & Negative. Screw Type Connection for ring terminal cables to anchor wire for solderless connection. Dual Hot Jaws for better power distribution. Includes Phillips anchor screws. Does not include hardware for cables, (ring terminals, solder etc...).

Discontinued - replaced by 238-006-666
249-093-900 Black Negative Booster Clamp 249-093-900 Black Negative Booster Clamp

Black Negative Booster Clamp features full power jaws (distributes full power to both jaws), heavy duty construction for durability and long life, solid copper jaws for better conductivity, and a braided internal power crossover strap instead of wire for even power to the jaws.

Price $15.06
249-094-900 Red Positive Booster Clamp 249-094-900 Red Positive Booster Clamp

Red Positive Booster Clamp features full power jaws (distributes full power to both jaws), heavy duty construction for durability and long life, solid copper jaws for better conductivity, and a braided internal power crossover strap instead of wire for even power to the jaws.

Price $15.06
316-014-000 Fan Blade 6" 4 Blade CW 316-014-000 Fan Blade 6" 4 Blade CW

316-014-000 Fan Blade 6" 4 Blade CW

Discontinued see 316-009-000
865-366-666  Rectifier With Insulators (New Style) 865-366-666 Rectifier With Insulators (New Style)

865-366-666  Rectifier With Insulators (New Style) replaces older 8 diode rectifier.

Discontinued
K3149-1 Century 40/20/2/200/130 Amp 6/12 Volt Automotive Battery Charger Starter Tester K3149-1 Century 40/20/2/200/130 Amp 6/12 Volt Automotive Battery Charger Starter Tester

The Century K3149-1 Automotive battery charger has features found on most commercial chargers at a price that can't be beat. A 200 amp 12v engine start helps start stubborn Engines and a 40 amp high, 20 amp medium and 2 amp low 12v charge settings for maximum range for most automotive batteries. 130 amp start and 40 amp high 6v charge setting for farm and fleet duty. A Low 2 amp setting is ideal for charging 12 volt motorcycle and lawn mower batteries. The Test feature identifies 12V battery and alternator problems, as well as indicates battery state of charge. Charges 6 & 12 volt maintenance free, conventional wet, deep cycle, AGM, and gel batteries used in cars, trucks, farm equipment, RV, boats and commercial applications.

Price $375.00
K3150-1 Century 60/40/2/250/185 Amp 6/12 Volt Automotive Battery Charger Starter Tester K3150-1 Century 60/40/2/250/185 Amp 6/12 Volt Automotive Battery Charger Starter Tester

The Century K3150-1 Automotive battery charger has features found on most commercial chargers at a price that cant be beat. A 250 amp 12v engine start helps start stubborn Engines and a 60 amp high, 40 amp medium and 2 amp low 12v charge settings for maximum range for most batteries. 185 amp start and 60 amp high 6v charge setting for farm and fleet duty. A Low 2 amp setting is ideal for charging 12 volt motorcycle and lawn mower batteries. The Test feature identifies 12V battery and alternator problems, as well as indicates battery state of charge. Charges 6 & 12 volt maintenance free, conventional wet, deep cycle, AGM, and gel batteries used in cars, trucks, farm equipment, RV, boats and commercial applications.

Price $399.00
K3151-1 Century 60/40/30/160/225 Amp 6/12/24 Volt Fleet Automotive Battery Charger Starter K3151-1 Century 60/40/30/160/225 Amp 6/12/24 Volt Fleet Automotive Battery Charger Starter

The Century K3151-1 Fleet Automotive battery charger has the power you need at a price that cant be beat. A 225 amp 12v engine start helps start large trucks and commercial engines and a 60 amp high, 40 amp medium 12v charge settings for most batteries. 30 amp 24v charge setting. 160 amp start and 60 amp high 6v charge setting for farm and fleet duty. The Test feature identifies 12V battery and alternator problems, as well as indicates battery state of charge. Charges 6, 12 & 24 volt maintenance free, conventional wet batteries used in cars, trucks, farm equipment, RV, boats and commercial applications.

Price $499.00
TJ1-120MHB Universal Battery Charger 2 Hour Mechanical Timer TJ1-120MHB Universal Battery Charger 2 Hour Mechanical Timer

TJ1-120MB Universal Mechanical 2 Hour Timer With Finish Bell. Mechanically controls charging in timed Mode, has "Hold" for manual un-timed charging. Single Pole Single Throw (SPST) Switch rated 15 amperes. Termination is designed to accept 1/4" Quick Disconnect terminals. Includes mounting screws. Replaces many older mechanical timers.

Discontinued see 0099000094
