Century / Solar Plasma Torch Stand-Off Kit keeps nozzle clear of dirt, paint and corrosion. Also simplifies cutting with straightedge or pattern. 131-280-908 TORCH STANDOFF Replaces 4416 / 44160.

216-082-000 Fan Motor With Leads 240 Volt .20 amps C.W. shaft end. Replaces some older models. 216-086-000, 216-086-010, 216-034-000, 216-034-100, 216-034-200, 216-034-666. See 316-007-300 for Fan blade.

216-086-666 Fan Motor W/ Leads 240 Volt .55 amp C.W. shaft end rotation. Replaces 216-034-000, 216-034-100, 216-034-200, 216-034-666. See 216-082-000 as a possible replacement.

238-240-999 TORCH HEAD FOR 238-240-100, 20 Amp, Used on 15-22 Amp models 118-008 (YA2230), 118-009 (82020, PSC20, 3W722), 118-010 (2020), 118-011 (YA2120), 118-012 (2010), 118-013 (5Z135, 82015).

238-244-666 Cable, Ground & Clamp Assembly

244-080-666 244-076-666 Century Rectifier Plasma

245-105-666 Century 2 Ohm 420 Watt Resistor comes with mounting brackets, insulators and mounting harware.

246-086-666 Century Solenoid 24 Volt Air Service, replaces 246-212-666 and 43700008, B7161370.

Plasma Torch Handle Assembly, no hardware included. Molded handles only for 238-240-100

334-274-100 Trigger Assembly Replaces 334-281-100

Century / Solar Style Electrode. Plasma Cutting Electrodes initiate the high intensity cutting arc and provide the contact necessary for arc maintenance. Electrodes are subject to wear, causing arc to weaken or be intermittent.

Century / Solar Style Electrode. Plasma Cutting Electrodes initiate the high intensity cutting arc and provide the contact necessary for arc maintenance. Electrodes are subject to wear, causing arc to weaken or be intermittent.

Century / Solar Style Plasma 40 Amp Swirl Ring. Swirl Ring imparts a swirling current to stabilize the arc. Keep your plasma cutter working at peak performance with these replacement parts.

Century - Solar Style 15 / 20 Amp Plasma Cutting Nozzles. The Plasma Cutting Nozzle controls arc for smooth cutting. When Purchasing a pair of Nozzles and nozzle caps, they must be the same style and amp rating (i.e. tapered, 15/20 amp).

Century - Solar Style 15 / 20 Amp Plasma Cutting Nozzles. The Plasma Cutting Nozzle controls arc for smooth cutting. When Purchasing a pair of Nozzles and nozzle caps, they must be the same style and amp rating (i.e. tapered, 15/20 amp).

Century / Solar Style Nozzle Cap, Tapered Type. Nozzle Caps direct cooling air flow to the nozzle and workpiece.

Century / Solar Package of 2 O-Rings for 20/40, 15, 20 and 50 amp plasma cutters. The rubber O-Ring prevents air leaks which cause erratic cutting and cooling.

880-027-666 Century Resistor 5 Ohm 50 watt Resistor

This Operators manual provides information for your specific model. This manual contains information such as the Important Safety Instructions, Usage and Maintenance of your plasma cutter. Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. This document is provided as a download PDF format. We suggest you save it to your computer for future reference.
